15HP S500 Horizontal Gasoline Engine

SKU:
Availability:
Quantity:
facebook sharing button
twitter sharing button
wechat sharing button
whatsapp sharing button
sharethis sharing button
ModelS500
TypeAir-cooled,4-cycle,single cylinder,side valve
Bore*Stroke(mm)94*72
Displacement (cc)500
Compression Ratio8.5:1
Max. Power Output (HP/rpm)18/3600
Max. Torque(N.m/)31
lgnition Systemlgnition System Non-contact transistorized ignition (T.C.I)
Starting SystemRecoil/Electric
Air CleanerSemi-drypil bath, dual, double silent and cyclone type
Fuel Tank (L)6.9
Oil Capacity (L)1.2
Fuel Consumption (g/kw-hour)≤374
Dimension(L* W* H)mm475*425*440
G.W/NW (Kg)39/36


Jiangsu Excalibur Power Machinery Co.,Ltd. was founded in November 2014 (be referred as “Excalibur”), we are an expert special-ized in manufacturing: Engines,Generators,Water Pumps Light construction equipmentsGardon and Agriculture machinery.
